180° Hinge, Zinc die light green powder-coated
180° Hinge, Zinc die light green powder-coated
180° Hinge with steel splint, Zinc die black powder-coated
180° Hinge with steel splint, Zinc die black powder-coated

180° Hinge, Zinc die dark green powder-coated; 1110-U3-HU

https://www.emka.com/products/1110-u3-hu-180-hinge-zinc-die-dark-green-powder-coated-218865 https://www.emka.com/web/image/product.template/218865/image_1920?unique=c82ea05

    This combination does not exist.

    Single cabinets Left Right
    No stock item, please ask for availability
    Internal Reference: 1110-U3-HU
    Barcode: 1110-U00003-00000HU
    Product Type: Hinge
    Program: 1110
    Material of the module : Zinc die
    Surface of the module: dark green powder-coated
    Dimension A, Variable: 20 mm
    Type of attachment to the frame: clamp-on / clip fix
    Type of fastening on the door: screw-on from outside, for countersunk screw small head M6
    Hole pattern required in the door: Notch in the door
    Max Opening Angle: 180°
    Suitable for door thickness from: 1.50 mm
    Suitable for door thicknesses up to: 2 mm
    Cabinet type : Single cabinets
    Door position: prominent
    Door Version : Left,Right
